Description
Features
- Various display interfaces: Dual-LVDS, EDP, HDMI etc.
- Various expansion interfaces. CX3568-A has six USB ports(A USB3.0 HOST standard port,a
USB3.0 OTG standard port, four internal expansion ports, there expansion ports from USB_HUB, one from CPU), two TTL serial ports, two RS232 serial ports, a 485 port, a 12I/O channel GPIO port , it can satisfy your customization request. - Various internet interfaces:a 1000M Ethernet interface, 2.4G WIIF and BT5.2 supported, built-in
PCI-E 4G module interfaces. - High definition.CX3568-A supports 4K/60HZ output, it also supports display screen with
LVDS/EDP/MIPI/HDMI interface. - Android system customization. CX3568-A provides system calling interface and API reference code,
it supports upper-layer applications development perfectly. - CX3568-A supports infrared, optical, capacitance, resistance and other mainstream touch screen.
